Introduction: Why Titanium Bolts Are a Big Deal
Why could a small screw trigger an industrial revolution?
You’ve probably seen titanium bolts in action—holding together high-end bikes, securing parts on race cars, or even in aerospace tech.
Many people are curious:
✓ How Strong Are Titanium Bolts？
✓ Are titanium screws really harder than steel?
✓ Why do top sports cars all use it?
✓ Is the claim of “never rusting” just a marketing gimmick?
In fact, all the answers are hidden in the key word “intensity”. Titanium screws are neither as heavy as steel nor as fragile as aluminum. With its unique strength formula: tensile strength + corrosion resistance + weight ratio, it has created miracles in fields such as aerospace and medical implants.
Strength Analysis of Titanium Bolts | How Strong Are Titanium Bolts?
Key Strength Metrics
Tensile Strength：
How much tensile force can titanium bolts withstand? The common Gr 5 titanium bolts tensile strength is 900-1000 MPa, which is nearly twice as high as ordinary steel. This is the core indicator for measuring how much tensile force a bolt can withstand before breaking.
Yield strength:
The yield strength of titanium alloy (the critical point at which the material begins permanent deformation) can reach over 800 MPa. It means that it is more resistant to deformation under heavy loads. Even when pulled to the deformed edge, titanium bolts can still remain stable, which is crucial for precision equipment such as aircraft engines.
Fatigue Resistance:
The cyclic load life of titanium bolts is 40% longer than that of steel bolts, making them particularly suitable for scenarios with frequent vibrations, such as aircraft engines or racing car components.
4 Factors That Determine Titanium Bolt Strength
Alloy Type
✓ Grade 2 (Pure titanium) : It has relatively low strength but is corrosion-resistant and suitable for chemical equipment.
✓ Grade 5 (Ti-6Al-4V) : The most commonly used high-strength alloy and the first choice for aerospace.
✓ Grade 23 (Medical grade) : Bio-compatibility is preferred, with slightly lower strength.
Heat Treatment
β annealing treatment can increase the strength of titanium bolts by 15-20% and optimize performance by altering the crystal structure.
Surface Treatments
Anodic oxidation treatment adds scratch resistance and prevents galvanic corrosion. It can also reduces surface microcracks, indirectly increasing fatigue life by 30%.
Temperature Tolerance
Titanium remains stable within the range of -250°C to 600°C, while steel bolts soften rapidly above 420°C.
Why This Matters?
Titanium bolts aren’t just “strong”—they’re precision-engineered for specific stresses. Whether you’re building a race car or a deep-sea robot, understanding these factors ensures optimal performance.
The Ultimate Showdown: Titanium Bolts vs Other Materials
Titanium vs Steel Bolts
✓ 45% lighter weight with comparable tensile strength (Grade 5 titanium: 900 MPa vs ASTM A574 steel: 860 MPa)
✓ 10 times longer lifespan in saltwater environments, proven by marine engineering studies
✓ -250°C to 600°C operational range vs steel’s vulnerability to embrittlement below -40°C
Titanium vs Aluminum Bolts
✓ 2-3 times higher tensile strength (Gr 5 Ti: 900 MPa vs 7075 Al: 390 MPa)
✓ Maintains 85% strength at 300°C vs aluminum’s 50% strength loss at 150°C
✓ Zero galvanic corrosion risk when paired with carbon fiber.2
Top 10 Applications of Titanium Bolts
Aerospace
Titanium bolts are the “invisible heroes” of aircraft structures. Take the Boeing 787 as an example. 20% of the connection points of its fuselage use titanium bolts, which reduces the weight by 15% compared with traditional steel and significantly lowers fuel consumption.
Medical Implants
Medical-grade titanium bolts (such as Ti-6Al-4V ELI) have passed the FDA certification, are perfectly compatible with human bones, and reduce the postoperative infection rate by 70%. They are the gold standard for orthopedic fixation.
Racing Cars/High-Performance Vehicles
The engine connecting rods of F1 racing cars use titanium bolts, reducing the weight of each bolt by 30 grams. The total weight of the car has been reduced by 4.2 kilograms, and the straight-line acceleration performance has been improved by 0.3 seconds.
Marine engineering
The drilling platform of Beihai Oilfield adopts titanium bolts, which have a service life of up to 30 years in salt spray environment, five times that of ordinary stainless steel, and the maintenance cost is reduced by 60%.
Bicycle
Professional teams use titanium bolts for assembly. The anti-vibration performance has been enhanced by 40%.
Chemical equipment
In the acidic environment of the PTA reactor, the annual corrosion rate of titanium bolts is only 0.002mm.
Outdoor equipment
Titanium bolts for mountaineering drones, zero failure under extreme temperature differences ranging from -40 ℃ to 150 ℃.
3D printing customization
NASA’s Mars probe uses 3D printed titanium bolts with a tolerance accuracy of ± 0.01mm.
FAQs of Titanium Bolts
Q: Can titanium bolts be used in high-temperature engines?
Yes, the Grade 5 titanium bolt (Ti-6Al-4V) still maintains 85% strength in an environment of 400°C (verified by SAE AS7245 standard). The case of Boeing 787 turbine fixing bolts shows that its heat resistance is 60% higher than that of traditional steel bolts. However, it should be noted that nickel-based alloys are recommended when the temperature exceeds 540°C.
Q: How to install titanium bolts correctly?
lean the threads (Residual non-metallic substances can cause cold welding)
Lubricant selection: Grease containing molybdenum disulfide (reducing the coefficient of friction by 40%
Torque reference table:
| Standard torque of bolt diameter (Nm) | |
| M6 | 10-12 |
| M8 | 22-26 |
| M10 | 42-48 |
Q: Will titanium bolts react with aluminum components?
It can cause galvanic corrosion, but it can be solved through the following solutions:
Use nylon washers, teflon coating or reduce inspection cycle to six months.
Conclusion: When Should You Choose Titanium Bolts?
Titanium bolts aren’t for every job, but they’re a game-changer in three scenarios:
When Every Gram Matters
Think: race cars, pro bikes, aircraft parts. Titanium is nearly 45% lighter than steel but just as strong.
When Your Gear Faces “Extreme Mode” Conditions
Saltwater? Acid fumes? Engine heat? Titanium resists corrosion and handles 300°C+ temperatures, cutting repair costs.
When You Want Long-Term Savings
Though 3-5 times pricier than steel, titanium pays off if a failed bolt could cause $10,000+ downtime.
Need titanium bolts? contact us to discover a professional titanium bolts manufacturer.
